Sweating Manikin System

This is some text inside of a div block.

State-of-the-art thermal manikin system combined with a high-precision water dosing system.

Typical split of 22 body zones (can be re-configured depending on needs).

‍

Male body-shape based on population data 22-30 body zones with independent measurement of skin temperature and heat flux
Analysis of equivalent temperature, global thermal comfort indices and local sensation indices
Calculation of thermal and evaporative resistance of clothing, for the total body or selected zones
Sweating capacity of 0 - 1000 ml/m2/hour
130 or 260 sweat glands, each individually controlled, enabling a very precise dosing of sweat
Special wicking skin optimizing the distribution of water on the surface of the manikin.
Rapid heat-up to setpoint, typically less than 10 min
Unique wire system that eliminates control delay and ensures a 100% stable set point
A dense 2,2 mm wiring optimized to create a uniform heat loss across the full body surface
Maximum sensitivity with heating wire and sensing only 0,2 mm under the paint
Can be operated in all environments with ambient temperatures ranging from -20 to +50 degrees
Cast in high quality glass fiber with robust joints, covered in a heat conducting compound.
Operated through an intuitive PC SW with a graphical user interface and 4 control modes
Can be placed standing, sitting or laying down depending on the application.
Option to include external breathing system with or without heating and humidification of the exhale air
Complies with all relevant ISO and ASTM standards

Software specifications:
